LED Conceal/Down Light
| Conceal Downlight | ||||||||
| Power | Size (mm) | Cut Out (mm) | PF | Lumen | CRI | Beam Angle | Surge | Housing |
| 3W | 85 mm | ɸ45 mm | >0.95 | 300lm | >80 | 120o | >4kV | PC |
| 3W | 85 mm | ɸ45 mm | >0.95 | 300lm | >80 | 120o | >4kV | PC |
| 7W | 105 mm | ɸ75 mm | >0.95 | 700lm | >80 | 120o | >4kV | PC |
| 7W | 105 mm | ɸ75 mm | >0.95 | 700lm | >80 | 120o | >4kV | PC |
| 7W | 105 mm | ɸ75 mm | >0.95 | 700lm | >80 | 120o | >4kV | PC |
| 7W | 105 mm | ɸ75 mm | >0.95 | 700lm | >80 | 120o | >4kV | PC |
| 8W | 106 mm | ɸ75 mm | >0.95 | 800lm | >80 | 120o | >4kV | Aluminium |
| 8W | 106 mm | ɸ75 mm | >0.95 | 800lm | >80 | 120o | >4kV | Aluminium |
| Colour | CW/NW/WW R/G/B/P |
| Colour Temp | 6500K/4000K/3000K |
| Input Voltage | AC 90V-300V |
| Life up to | 25000 Hrs |
| Operating Temp | -25oC to 50oC max |
| Driver | Internal |
● Aluminium heat sink inside for better heat dissipation and longer life.
● Complete Aluminium housing in higher rating as 8W & 9W for better heat dissipation and longer life .
● Flicker Free light with life upto 25000 hrs (15 years at 4.5 hours per day).
● Suitable for Home, Hotels, Colleges, Schools, Guest Houses, Ware Houses, Office Interiors, corridor, showrooms etc.
● Complete Aluminium housing in higher rating as 8W & 9W for better heat dissipation and longer life .
● Flicker Free light with life upto 25000 hrs (15 years at 4.5 hours per day).
● Suitable for Home, Hotels, Colleges, Schools, Guest Houses, Ware Houses, Office Interiors, corridor, showrooms etc.
